CNC drilling machine is mainly used for drilling, reaming, chamfering, etc. It is mainly used in automobile, mold, shipbuilding, aerospace, construction machinery industries, especially for some hardware parts that have multiple holes to be processed. When drilling hardware parts in a straight line, a CNC drilling machine is required. The existing CNC drilling machine for workpiece processing is inconvenient to adjust the distance. After one drilling, the fixed workpiece needs to be re-fixed. , increase the work intensity and reduce the work efficiency of the CNC drilling machine.
A CNC drilling machine for workpiece processing launched by GooDa Machinery has the advantage of convenient adjustment of the distance, which solves the inconvenient adjustment of the distance of the existing CNC drilling machine for workpiece processing. The fixed workpiece is re-fixed, which increases the work intensity and reduces the work efficiency of the CNC drilling machine. Provide the following technical solutions:
A CNC drilling machine for workpiece processing comprises a base, a column is fixedly connected to the left side of the top of the base, a chute is opened on the right side of the column, and a horizontal plate is fixedly connected to the top of the right side of the column. The top of the horizontal plate of the drilling machine is fixedly connected with a first motor, the bottom of the output end of the first motor penetrates to the bottom of the horizontal plate and is fixedly connected with a first threaded rod, and the bottom of the first threaded rod of the drilling machine is movably connected to the base through a bearing The right side of the first threaded sleeve is fixedly connected with a connecting plate, the right side of the drilling machine connecting plate is fixedly connected with a fixed sleeve, and the inner ring of the fixed sleeve is fixedly connected with a second motor, head, front and rear on the right side of the top of the base both sides are fixedly connected with vertical plates. The inner side of the vertical plate of the drilling machine is fixedly connected with a sliding rod, the surface of the sliding rod is sleeved with a fixed shell, and the front and rear sides of the top of the placing board are fixedly connected with a fixed board. The inner side of the fixing plate of the drilling machine is fixedly connected with an electric telescopic rod, and the inner side of the electric telescopic rod is fixedly connected with a splint. The front surface of the fixing shell of the drilling machine is fixedly connected with a second threaded sleeve, and the inner cavity of the second threaded sleeve is threadedly connected with a second threaded rod.
The beneficial effects of the CNC drilling machine are as follows: he CNC drilling machine can be used in conjunction with the placement plate, the support sleeve, the vertical plate, the fixed shell, the second threaded sleeve, the second threaded rod and the sliding rod, and after one drilling , the workpiece is moved rapidly, the processing efficiency is improved, and the existing CNC drilling machine for workpiece processing is inconvenient to adjust the distance. After one drilling, the fixed workpiece needs to be re-fixed, which increases the work The strength reduces the problem of the working efficiency of the CNC drilling machine.
• The base of the working table and the column is connected with the design, and the rigidity of the machine can be enhanced.
• Suitable for small parts, mold processing, thimble, runner and medical products etc..
• Small size, easy to display, processing aperture of up to 2mm.
The main axis of the distribution is 1mm, which is the smallest of the same level.
ER40 spindle machining aperture: 2-25mm (this is the standard configuration).
• X, Y, Z travels: 600x600x600mm.
• Table load: 5 tons.
Precision lead to the use of high speed motorized spindle (optional), processing diameter of up to 1 mm, the speed of up to 30 mm per minute (this is a special configuration).
Electro spindle machining aperture: 1-12mm.
Motorized spindle speed: 4000-15000r.p.m.
Electric spindle machining feed rate: 10-60mm/min.
