Horizontal Machining Center WJ-1815

X/Y/Z Travel: 1800*1500*850mm

Spindle RPM: 3000rpm/6000rpm

Model:
WJ-1815
Brand:
GOODA

Availability:

Quantity:



Inquire

Function Introduction of the WJ-1815

size of horizontal machining center-WJ-1815

DooDa Horizontal Machining Center WJ-1815 adopts an ultra-large size inverted "T" type bed base, and the Y-axis adopts a double-layer wall moving column structure with high rigidity and durability, suitable for heavy-duty cutting, roughing, semi-finishing applications.

To enhance the roughing function, a customized thicken spindle is adopted, equipped with a 30 KW high-torque motor, suitable for precision molds, engineering machinery, automotive, locomotives, ships, marine engineering, and other industries.

Advantages

1. Bed & Base

The inverted "T" type bed structure ensures that the machine tool has sufficient rigidity and stability during operation, reduces machine tool vibration, and improves tool life.

machine base

2. Head

2 extended heavy-duty 55# roller linear guides ensure high resistance to vibrations. The spindle box has a nitrogen balance system to improve the machine tool dynamic response speed.

machine head

3. Spindle

Increased spindle sleeve diameter enhances the cutting rigidity, with spindle RPM reaching up to 3000rpm/6000rpm. The spindle is equipped with a cooling system to ensure long-term stable operation.

machine spindle

4. Z-axis

The Z-axis motion is the entire movement of the column. The rigidity of the Z-axis and the spindle head remains consistent throughout the full travel of the Z-axis, reducing tool vibration during deep cavity machining.

z-axis

5. Protection Cover

The machine is equipped with a semi enclosed protective cover to enhance safety.

protection cover

6. Column

The Y-axis adopts a double-layer wall moving column structure, made of high-quality HT-300 cast iron with secondary annealing treatment, ensuring deformation resistance, excellent accuracy and stability, and long service life.

column

Related Products

Horizontal Machining Center WJ-3020

Horizontal Machining Center WJ-2515

Horizontal Machining Center WJ-2015

WJ-1815		Value	Unit
Travel	X/Y/Z Travel	18001500850	mm
Worktable	Size	2000*1300	mm
	Max. load	15000	KG
Spindle	Spindle Taper	BT-50-φ220	/
	Spindle drive	Belt drive	/
	Spindle RPM	3000/6000	rpm
	Distance from spindle center to worktable	135-1635	mm
Feed	Guideway	X/Y/Z axis: roller rail guide	/
	X/Y/Z Rapid feed rate	10/10/10	m/min
	Max. cutting feed rate	8/8/8	m/min
Machine weight & size	Size (LWH)	480053554100	mm
Machine weight & size	Weight	~16000	KG

WJ-1815		Value	Unit
Travel	X/Y/Z Travel	18001500850	mm
Worktable	Size	2000*1300	mm
	Max. load	15000	KG
Spindle	Spindle Taper	BT-50-φ220	/
	Spindle drive	Belt drive	/
	Spindle RPM	3000/6000	rpm
	Distance from spindle center to worktable	135-1635	mm
Feed	Guideway	X/Y/Z axis: roller rail guide	/
	X/Y/Z Rapid feed rate	10/10/10	m/min
	Max. cutting feed rate	8/8/8	m/min
Machine weight & size	Size (LWH)	480053554100	mm
Machine weight & size	Weight	~16000	KG
